Attribute
Description
Manufacturer Part Number
NTZD3155CT2G
Manufacturer
Description
MOSFET N/P-CH COMPL 20V SOT-563
Note :
GST will not be applied to orders shipping outside of India
Stock: 1
Distributor: 3
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 40.89 | ₹ 40.89 |
| 50 | ₹ 23.95 | ₹ 1,197.50 |
| 100 | ₹ 11.36 | ₹ 1,136.00 |
| 250 | ₹ 11.08 | ₹ 2,770.00 |
| 500 | ₹ 10.70 | ₹ 5,350.00 |
| 1000 | ₹ 7.48 | ₹ 7,480.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| FET Type | N and P-Channel | |
| Drain to Source Voltage (Vdss) | 20V | |
| Current - Continuous Drain (Id) @ 25°C | 540mA, 430mA | |
| Rds On (Max) @ Id, Vgs | 550 mOhm @ 540mA, 4.5V | |
| Vgs(th) (Max) @ Id | 1V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 2.5nC @ 4.5V | |
| Input Capacitance (Ciss) @ Vds | 150pF @ 16V | |
| Power - Max | 250mW | |
| Mounting Type | Surface Mount | |
| Package / Case | SOT-563, SOT-666 |
Description
Measures resistance at forward current N and P-Channel for LED or diode evaluation. Peak Rds(on) at Id 550 mOhm @ 540mA, 4.5V for MOSFET efficiency.
