RJH1BF7RDPQ-80#T2
Data Sheet
Attribute
Description
Manufacturer Part Number
RJH1BF7RDPQ-80#T2
Manufacturer
Description
IGBTs - Single,
1100V,
60A,
250W
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| IGBT Type | - | |
| Voltage - Collector Emitter Breakdown (Max) | 1100V | |
| Current - Collector (Ic) (Max) | 60A | |
| Power - Max | 250W | |
| Vce(on) (Max) @ Vge, Ic | 2.35V @ 15V, 60A | |
| Input Type | Standard | |
| Mounting Type | Through Hole | |
| Package / Case | TO-247-3 |
Description
Features a DC current gain hFE at Ic evaluated at 2.35V @ 15V, 60A. Peak Vce(on) at Vge 60A for transistor parameters.
