Attribute
Description
Manufacturer Part Number
PWR1303AC
Manufacturer
Description
PWR13xxC Series 1.5 W Dual Output ±5 V Isolated Through Hole...
Note :
GST will not be applied to orders shipping outside of India
Stock: 1
Distributor: 3
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 3,291.33 | ₹ 3,291.33 |
| 5 | ₹ 3,158.80 | ₹ 15,794.00 |
| 10 | ₹ 3,102.01 | ₹ 31,020.10 |
| 25 | ₹ 3,045.21 | ₹ 76,130.25 |
| 50 | ₹ 2,780.16 | ₹ 1,39,008.00 |
| 100 | ₹ 2,648.59 | ₹ 2,64,859.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Type | Isolated Module | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 5.5V | |
| Voltage - Output 1 | 5V | |
| Voltage - Output 2 | -5V | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 150mA, 150mA | |
| Power (Watts) - Manufacture Series | 2W | |
| Voltage - Isolation | 4kV (4000V) | |
| Mounting Type | Through Hole | |
| Package / Case | 24-DIP Module (9 Leads) | |
| Size / Dimension | 1.27 L x 0.81 W x 0.40 H (32.3mm x 20.5mm x 10.2mm | |
| Operating Temperature | -55°C ~ 100°C | |
| Efficiency | 0.75 |
Description
Measures resistance at forward current 2 for LED or diode evaluation. Peak Vce(on) at Vge 0.75 for transistor parameters.
