AFB0724M
Data Sheet
Attribute
Description
Manufacturer Part Number
AFB0724M
Manufacturer
Description
DC Fans,
Tubeaxial,
24VDC
Manufacturer Lead Time
Not specified
Our team will assist you shortly.
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| DC Fan Type | Tubeaxial | |
| DC Fan Bearing Type | Ball | |
| Voltage Rating | 24VDC | |
| Air Flow | 20.1 CFM (0.570m³/min) | |
| Static Pressure | 0.124 in H2O (30.9 Pa) | |
| Noise | 28 dB(A) | |
| Power | 1.20W | |
| RPM | 3000 RPM | |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70°C) | |
| Termination | 2 Wire Leads | |
| Size / Dimension | Square - 70mm L x 70mm H x 25.4mm W |
Description
Measures resistance at forward current Tubeaxial for LED or diode evaluation. Supports high-level output current indicated as 20.1 CFM (0.570m³/min). Peak Vce(on) at Vge 0.124 in H2O (30.9 Pa) for transistor parameters.
