74408942150

74408942150

Data Sheet

Attribute
Description
Manufacturer Part Number
74408942150
Manufacturer
WURTH ELEKTRONIK GMBH & CO KG
Description
POWER INDUCTOR, 15UH, 1.1A,...
Manufacturer Lead Time
Not specified

Our team will assist you shortly.

Product Attributes

Type Description
Category
Material - Core Powdered Iron
Inductance 15µH
Tolerance ±20%
Current Rating 1.1A
Current - Saturation 1.6A
Shielding Shielded
DC Resistance (DCR) 245 mOhm Max
Q @ Freq -
Frequency - Self Resonant 19MHz
Operating Temperature -40°C ~ 125°C
Frequency - Test 100kHz
Mounting Type Surface Mount
Package / Case 1919 (4848 Metric)
Size / Dimension 0.189" L x 0.189" W (4.80mm x 4.80mm)
Height - Seated (Max) 0.118" (3.00mm)

Description

Shop now for premium quality electronic components at competitive prices with fast shipping.

Similar Products

744052100
