2274-12-021
Data Sheet
Attribute
Description
Manufacturer Part Number
2274-12-021
Manufacturer
Description
RELAY REED SPST 500MA 12V
Note :
GST will not be applied to orders shipping outside of India
Stock: 1
Distributor: 1
Authorized
Lead Time: 3 Working Days
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 1,110.72 | ₹ 1,110.72 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Relay Type | Reed | |
| Coil Type | Non Latching | |
| Coil Current | 21.8mA | |
| Coil Voltage | 12VDC | |
| Contact Form | SPST-NO (1 Form A) | |
| Contact Rating (Current) | 500mA | |
| Switching Voltage | 200VAC, 200VDC - Max | |
| Turn On Voltage (Max) | 6.7 VDC | |
| Turn Off Voltage (Min) | 1 VDC | |
| Operate Time | 0.5ms | |
| Release Time | 0.1ms | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin |
Description
Measures resistance at forward current SPST-NO (1 Form A) for LED or diode evaluation. Shop now for premium quality electronic components at competitive prices with fast shipping.
