2404KL-04W-B50-B00
Data Sheet
Attribute
Description
Manufacturer Part Number
2404KL-04W-B50-B00
Manufacturer
Description
FAN DC AXIAL 12V 60X10.3MM
Note :
GST will not be applied to orders shipping outside of India
Stock: 199
Distributor: 2
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 1,034.25 | ₹ 1,034.25 |
Stock: 358
Distributor: 3
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 1,304.41 | ₹ 1,304.41 |
| 10 | ₹ 1,220.17 | ₹ 12,201.70 |
| 50 | ₹ 1,091.43 | ₹ 54,571.50 |
| 100 | ₹ 956.07 | ₹ 95,607.00 |
| 250 | ₹ 894.54 | ₹ 2,23,635.00 |
| 500 | ₹ 833.01 | ₹ 4,16,505.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| DC Fan Type | Tubeaxial | |
| DC Fan Bearing Type | Ball | |
| Voltage Rating | 12VDC | |
| Air Flow | 19.0 CFM (0.538m³/min) | |
| Static Pressure | 0.121 in H2O (30.1 Pa) | |
| Noise | 36 dB | |
| Power | 3.24W | |
| RPM | 4800 RPM | |
| Operating Temperature | 14 ~ 140°F (-10 ~ 60°C) | |
| Termination | 2 Wire Leads | |
| Size / Dimension | Square - 60mm L x 60mm H x 10.3mm W |
Description
Measures resistance at forward current Tubeaxial for LED or diode evaluation. Supports high-level output current indicated as 19.0 CFM (0.538m³/min). Peak Vce(on) at Vge 0.121 in H2O (30.1 Pa) for transistor parameters.
