2N7002V
Data Sheet
Attribute
Description
Note :
GST will not be applied to orders shipping outside of India
Stock: 11162
Distributor: 2
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 35.25 | ₹ 35.25 |
Stock: 2485
Distributor: 3
Lead Time: Not specified
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 45.06 | ₹ 45.06 |
| 10 | ₹ 31.90 | ₹ 319.00 |
| 100 | ₹ 14.77 | ₹ 1,477.00 |
| 1000 | ₹ 11.26 | ₹ 11,260.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| FET Type | 2 N-Channel (Dual) | |
| Drain to Source Voltage (Vdss) | 60V | |
| Current - Continuous Drain (Id) @ 25°C | 280mA | |
| Rds On (Max) @ Id, Vgs | 7.5 Ohm @ 50mA, 5V | |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA | |
| Gate Charge (Qg) @ Vgs | - | |
| Input Capacitance (Ciss) @ Vds | 50pF @ 25V | |
| Power - Max | 250mW | |
| Mounting Type | Surface Mount | |
| Package / Case | SOT-563, SOT-666 |
Description
Measures resistance at forward current 2 N-Channel (Dual) for LED or diode evaluation. Peak Rds(on) at Id 7.5 Ohm @ 50mA, 5V for MOSFET efficiency.
